MSI PM8M3-V VIA P4M800CE Socket 775 mATX Motherboard with Video, Sound & LAN

MSI PM8M3-V VIA P4M800CE Socket 775 mATX Motherboard with Video, Sound & LAN

The MSI PM8M3-V is a motherboard designed for building a reliable and efficient desktop computer system. It is based on the VIA P4M800CE + VT8237R Plus chipset and features a Socket 775 form factor, making it compatible with Intel Pentium 4 and Celeron D processors. This motherboard supports up to 2 GB of DDR RAM, with speeds of DDR400/333, providing sufficient memory capacity for basic computing tasks. It also includes integrated graphics via the S3 UniChrome Pro, eliminating the need for a separate graphics card for basic use. The Realtek ALC655 6-channel audio codec ensures high-quality sound output, while the Realtek RTL8201CL Ethernet LAN provides a 10/100 Mbps network connection.

The motherboard includes two Serial ATA (SATA/150) controllers, allowing for fast data transfer speeds of up to 150 Mbps with compatible hard drives. It also features an 8x AGP graphics interface, which allows for the installation of high-performance graphics cards if needed. Additionally, the onboard USB 2.0 ports support transfer speeds of up to 480 Mbps, ensuring quick data transfers between peripherals and the system. With its mATX form factor, this motherboard offers a compact yet feature-rich platform for building a capable desktop system.



Brand: MSI
Model: PM8M3-V
Specifications: VIA P4M800CE + VT8237R Plus chipset, Socket 775, mATX form factor, up to 2 GB DDR RAM (DDR400/333), S3 UniChrome Pro integrated graphics, Realtek ALC655 6-channel audio, Realtek RTL8201CL Ethernet LAN, two SATA controllers, 8x AGP slot, USB 2.0
Features: Supports Intel Pentium 4 and Celeron D processors up to 3.8 GHz, 800 MHz Front Side Bus, Intel Hyper-Threading Technology
