Digital RGB Black EKWB EK-Loop FPT 140mm Fan 600-2200 RPM
|
Prices shown may differ from Amazon due to dynamic updates, promotions, inventory changes, or item condition (new/used/refurbished).
The final price and availability are confirmed on Amazon at checkout.
Learn more.
|
|
Buy on Amazon
|
|
|
As an Amazon Associate, we earn from qualifying purchases. Prices and availability change frequently;
the final terms are displayed on Amazon’s website at the time of purchase.
Pricing Policy.
|
|
| Brand: | EK |
EKWB EK-Loop FPT 140mm Fan is a high-static pressure cooling solution designed for advanced liquid cooling systems. It offers a wide RPM range from 600 to 2200, allowing users to balance between cooling efficiency and noise levels. The fan features digital RGB lighting, which adds a customizable aesthetic to the system while maintaining performance.
The fan uses a Fluid Dynamic Bearing (FDB) for long-lasting durability, rated for up to 60000 hours at 25°C. It provides a maximum airflow of 118.01 CFM and static pressure of 3.57 mm H2O, making it ideal for high-performance radiators. The PWM duty cycle range of 20-100% allows precise control over fan speed and noise output.
The design includes a full frame that prevents air leakage, enhancing static pressure performance. The fan supports daisy-chaining through the EK-OmniLink system, reducing cable clutter with a single cable handling both PWM and D-RGB signals. The included extender cable offers flexibility in routing and connecting to the motherboard.
The package includes the fan, a cable extender with both PWM and D-RGB headers, and four self-tapping case screws for easy installation. The fan is compatible with most modern motherboards that support 4-pin PWM and 3-pin addressable RGB headers.
Brand: EKWB
Model: EK-Loop FPT 140 D-RGB
Specifications: 140mm x 140mm x 27mm, 600-2200 RPM, 12V, 5.5W power draw, FDB bearing, 3.57 mm H2O static pressure
Features: Digital RGB lighting, EK-OmniLink daisy-chaining, full frame design for improved static pressure, PWM control, included cable extender and mounting screws
The fan uses a Fluid Dynamic Bearing (FDB) for long-lasting durability, rated for up to 60000 hours at 25°C. It provides a maximum airflow of 118.01 CFM and static pressure of 3.57 mm H2O, making it ideal for high-performance radiators. The PWM duty cycle range of 20-100% allows precise control over fan speed and noise output.
The design includes a full frame that prevents air leakage, enhancing static pressure performance. The fan supports daisy-chaining through the EK-OmniLink system, reducing cable clutter with a single cable handling both PWM and D-RGB signals. The included extender cable offers flexibility in routing and connecting to the motherboard.
The package includes the fan, a cable extender with both PWM and D-RGB headers, and four self-tapping case screws for easy installation. The fan is compatible with most modern motherboards that support 4-pin PWM and 3-pin addressable RGB headers.
Brand: EKWB
Model: EK-Loop FPT 140 D-RGB
Specifications: 140mm x 140mm x 27mm, 600-2200 RPM, 12V, 5.5W power draw, FDB bearing, 3.57 mm H2O static pressure
Features: Digital RGB lighting, EK-OmniLink daisy-chaining, full frame design for improved static pressure, PWM control, included cable extender and mounting screws
